Item | Stage indoor P3 LED display |
Model Number | P3 |
Pixel Pitch | 3mm |
Pixel Density(dots/m²) | 111111 |
Pixel Configuration | RGB |
LED Type | SMD2121 |
Module size(mm) | 192*96 |
Module Resolution(dots) | 64*32 |
Min.Viewing Distance(m) | ≥3 |
Brightness(cd/m²) | ≥1200 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 500-750 |
Scan Mode | 1/16 |
Protection Level | IP21 |
Cabinet Size(mm) | Customized |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements |
Working temperature ： | -40°C~80°C Life Span: 100,000hours |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Control Type | Asynchronization (3G/ WiFi /USB )/Synchronization |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <120° |
Product Features
1) Cabinet weight is only 8.3 kg, decreasing the transportation cost and the intensity of labor.
2) Super thin power supply inside: Quiet fan design, excellent heat dissipation, noiseless.
3) Refresh rate＞1500HZ, 2 times higher than the regular screen, suitable for the rental occasion
which requires much more higher display capability.
4) Super-light aluminum alloy connectors are durable and artistic.
5) Signal & power aviation connectors are water & dust proof, stable and reliable.
6) Cushion under the cabinet can protect the modules from being damaged.
Important Knowledge of LED Display
1.How long could I receive the inquiry reply ?
You will get a reply within 24 hours.
2.What kind of led display do you offer ?
Different product offer different time frame warranty, but all product here we offer 1 year at least warranty
3.How is the after sales service ?
We have a professional team which is in all around the world , also a service hot-line dealing with your complains and feedback.We also offer 24-hour online service to help you solving problems
4.How long will it take to deliver goods ?
We will start preparing goods when we get your bank receipt. The package will be shipped out in 1-2 working days after we get your payment.
5.Are you a factory or trading company?
We are a factory.
To receive a catalog,pricing information and a sample of a sign for your needs,just leave an Inquiry to get a Quick Quotation by those contact way.
