Item | Stage indoor P4 LED display |
Model Number | P4 |
Pixel Pitch | 4mm |
Pixel Density(dots/m²) | 62500 |
Pixel Configuration | RGB |
LED Type | SMD2121 |
Module size(mm) | 256*128 |
Module Resolution(dots) | 64*32 |
Min.Viewing Distance(m) | ≥4 |
Brightness(cd/m²) | ≥1200 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 500-750 |
Scan Mode | 1/16 |
Protection Level | IP21 |
Cabinet Size(mm) | Customized |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level;Color temperature is adjustable in terms of detailed requirements |
Working temperature | -40°C~80°C Life Span: 100,000hours |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Control Type | Asynchronization (3G/ WiFi /USB )/Synchronization |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <120° |
Product Features
1) SMD technology, better color uniformity than DIP. Special design for rental.
2) Ultra-thin design, handle bar also available.
3) Ultra-thin power supplier.
4) 1500HZ, 2 times higher than the regular screen, suitable for the rental occasion
which requires much more higher display capability.
5) Cabinet size is customizable without any extra cost.
6) High refresh rate, high gray level: It can reach 16bit by using MBI driving IC.
Important Knowledge of LED Display
1.Whats your payment term? How long it takes to delivery?
We accept T/T and L/C, For both T/T and L/C, At least 40% deposit in advance, and the rest 60% before delivery.
Our average Production time is 15 days, after receiving the deposit.
2. What's the control system?
For synchronization control: We use Nova, Linsn Or Colorlight control system.
For asynchronous control: We use Onbon, or Xixun control system.
3.How can i place an order?
Please inform your requirements as clear as possible. So we can send you the offer ASAP.it is better to contact us
with Skype/email /phone within project begining, in case of any delays.
4.What kind of display we provide?
We have indoor/outdoor/mobile LED /rental LED display /LED stage/LED Dance Floor/Irregular LED display/stadium
LED Display for you choose.
5.What about the lead time for order?
Always: 3-20 days, as your order quantity, sometimes we have stock, can delivery within 7 days.
