Item | Stage indoor P2.5 LED display |
Model Number | P2.5 |
Pixel Pitch | 2.5mm |
Pixel Density(dots/m²) | 160000 |
Pixel Configuration | RGB |
LED Type | SMD2121 |
Module size(mm) | 160*160 |
Module Resolution(dots) | 64*64 |
Min.Viewing Distance(m) | ≥2.5 |
Brightness(cd/m²) | ≥1200 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 350-600 |
Scan Mode | 1/32 |
Protection Level | IP21 |
Cabinet Size(mm) | Customized |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements |
Working temperature | -40°C~80°C Life Span: 100,000hours |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Control Type | Asynchronization (3G/ WiFi /USB )/Synchronization |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <120° |
Product Features
1) Cabinet weights only 8.3 kg, decreasing the transportation cost and the intensity of labor.
2) Super thin power supply inside, Quiet fan design, excellent heat dissipation, noiseless.
3) Refresh rate up to 1200HZ, 2 times higher than the regular screen, suitable for the rental .
occasion which requires much more higher display capability.
4) Super-light aluminium alloy connectors are durable and artistic.
5) Signal & power aviation connectors are water & dust proof, stable and reliable.
6) Cushion under the cabinet can protect the modules from being damaged.
Important Knowledge of LED Display
1. What can I show on my LED Screen?
The answer is pretty much anything. From Jpegs and still images to a Full HD video. From a single line of text to a cricket scoreboard. TV, Foxtel, PC display, Custom Graphics. As long as you have the correct size and resolution on your screen, anything is possible.
2. Why are your LED Screens and Scoreboards so much cheaper than anybody else?
The simple answer to this question is mark-up. Over the last 5 years the cost of electronics has reduced significantly.
3. Can I have a sample order for led cabinet?
Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
4. What about the lead time?
Sample needs 7-10 days, mass production time needs 4-5 weeks.
5. Do you have any MOQ limit for led display order?
Low MOQ, 1pc for sample checking is available
To receive a catalog,pricing information and a sample of a sign for your needs,just leave an Inquiry to get a Quick Quotation by those contact way.
