Item | Outdoor P4.81 Rental LED Screen |
Model Number | P4.81 SMD2727 |
Pixel Pitch | 4.81 mm |
Pixel Density(dots/m²) | 43222 |
Pixel Configuration | 3 IN 1 |
LED Type | SMD2727 |
Module size(mm) | 250mm*250mm |
Module Resolution(dots) | 52*52 dots |
Min.Viewing Distance(m) | ≥4.81 |
Brightness(cd/m²) | ≥7000 |
Viewing Angle(degree) | ≤140° |
Average Power Consumption(w/m²) | 550-850 W |
Scan Mode | 1/ 16 |
Protection Level | IP65 |
Iron Cabinet Size(mm) | 500mm*500mm |
Color Temperature | The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements |
Permeation rate | 40% |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <140° |
Gray Scale | Recommended 14BIT |
Effective Communication Distance(without relay) | Unshielded twisted-pair net line transmission distance is 100 meters,max transmission distance is 130 meters. |
Lifespan | ≥100000 hours |
Environment Temperature | Storage: -40°C ~ +85°C |
Blind Spot Rate | ＜0.0001(led display industry standard is less than 0.0003) |
Control Mode | Video frequency synchronization |
Product Features
1. No Black Screen during Use: Constituted by loop transmission, intelligent switch, anti-hacker security and fault alarm, the most reliable data transmission mode is incorporated internally.
2. Safe Maintenance: It supports hot swapping, which is more safe and convenient for maintenance personnel.
3. Dislocation joining together: more art inspiration, more modeling.
4. Time-saving－Only one person can assemble at least 60 cabinets within 1 hour.
5. Ultra-thin－Maximum thickness is only 58mm, the thinnest edge is only 14mm; 1CMB can load 32 cabinets, saving much transportation cost.
6. High accuracy－Processed by electromechanical machining, the size is with the accuracy to 0.1mm.
Important Knowledge of LED Display
1. Can you manufacture customized shape, logo, and package?
Yes.
2. What is the warranty of your products?
The Warranty are 3-year, 2-year and 1-year warranty.
3. What is the lead-time for average order? What is the shipping time?
The lead-time for average order is 3-6 days. And 3-5 days by express ; 5-6 days by Air press.;25-35 days by Sea.
4. Why should I spend more on a full color LED as opposed to a monochrome display?
Monochrome LED displays have been utilized for years, and are proven, effective marketing tools. However, since they utilize only one color (red or amber), the visual messages that can be displayed are limited. Full color LED displays offer the full resolution of print billboards with the versatility that only LEDs can offer. This opens up limitless marketing possibilities including realistic images, video, and animation effects.
5. Is there any special issue between the standard led display and led perimeter/scoreboard?
The difference including:The mast of perimeter/scoreboard is soft, the cabinet has extra support from backside, the refresh rate is super high, and normally it will request fiber and fiber converter,also needs the scoreboard system.
To receive a catalog,pricing information and a sample of a sign for your needs,just leave an Inquiry to get a Quick Quotation by those contact way.
