Item | Outdoor Sports P10 led display |
Model Number | P10 |
Pixel Pitch | 10mm |
Pixel Density(dots/m²) | 10000 |
Pixel Configuration | RGB |
LED Type | DIP346 |
Module size(mm) | 320*160 |
Module Resolution(dots) | 32*16 |
Min.Viewing Distance(m) | ≥10 |
Brightness(cd/m²) | ≥7000 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 240-480 |
Scan Mode | 1/4 |
Protection Level | IP65 |
Cabinet Size(mm) | Customized |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level:Color temperature is adjustable in terms of detailed requirements |
Working temperature | -40°C~80°C Life Span : 100,000hours |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Control Type | Asynchronization (3G/ WiFi /USB )/Synchronization |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <120° |
Product Features
led mobile truck led display,truck led screen,no power truck display widely use for advertising campaigns,outdoor led billboard,concert and sport live,high brightness with high clarity
Important Knowledge of LED Display
1. How about the warranty ?
1-3 years warranty.
2. What is your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU, etc. You can choose the one which is the most convenient or
cost effective for you.
3. What kind of display we provide?
We have indoor/outdoor/mobile LED /rental LED display /LED stage/LED Dance Floor/Irregular LED display
/stadium LED Display for you choose.
4. What about the lead time for order?
Always: 3-20 days, as your order quantity, sometimes we have stock, can delivery within 7 days
5. What is LED display of the IP protection grade?
IP protection grade is composed of two digital, the first digital representation from the dust of lamps and lanterns,
the level of the external things out, the second digit said moisture proof.
To receive a catalog,pricing information and a sample of a sign for your needs,just leave an Inquiry to get a Quick Quotation by those contact way.
