Pixel pith | 10mm | Module size(mm) | 320 x 160mm |
Pixel configuration | 1R1G1B ( 3in1 ) | Module density(dots) | 32 x 16dots |
View Angle | 140°/120° | Pixel density | 10,000dots/㎡ |
LED encapsulation | SMD3528 3in1 | Refresh rates | ≥600Hz or ≥2000Hz |
Driving Method | 1/8 scan,constant current | Max power consumption | 600w/㎡ |
Cabinet size | Normal 640x 640mm or | Cabinet material | Aluminum alloy or Iron, Steel |
Cabinet thickness | < 8 cm or Designed by requirements | Cabinet weight | < 10kg/cabinet or Designed by require |
Brightness | >1600nits | Type Power consumption | 300w/㎡ |
Working voltage | AC110 / 220V +- 15% | Working temp | -20℃to +60℃ |
Best viewing distance | >6 m -300meter | Working humidity | 35%~85% |
LED parameters | R:620-625nm | MTBF | > 5,000hours |
G:520-523nm | Gray Level | > 8192 grade | |
B:467-470nm | Lifespan | > 100,000hours |
Image processing | Video de-noising , rapid motion compensation, edge sharpening, edge smoothing,color coordinate conversation& control , grey scale transformation etc |
Brightness uniformity | Ratio of min pixel brightness /max pixel<0.9(When each color reaches its highest brightness) |
Effective control distance | Cat-5<100M,Multi-mode fiber:<500M;Single-mode fiber<20Km |
Color Temperature/contrast | Brightness and contrast of red, green and blue can be adjusted by software,100 scales are available, color temperature is adjustable |
Input signal | RF,S-VIDEO,RGB,RGBTV,YUT,YC,COMPISITION |
Control system | Sending card+ Receiving card+ Hub card+ DVI Card+ PCTV Non-liner card+ Multi-functional card(Optional)+Video processor(Optional)+ Fiber Transmitter(Optional) |
1 High definition (10,000dots/sqm) with an outstanding image and video quality for indoor usage
2 Wide view angle:140 in horizonal and 90 in vertical.for indoor full color
3 High refresh rate (greater than 800Hz-4000Hz)with software adjustable, suitable for filming.
4 High gray scale (16 bits) with perfect visual performance.
5 High Contras ratio (3000:1) with black mask and black coating technique.
6 High color uniformity and clear image can bring you a vivid audio visual effect.
7 Special design and advanced SMT technology for indoor led screen
improves the heat dissipation for indoor led signboard
8 High reliability and long lifespan (MTBF ≥ 5000 hours).
9 Low power consumption(200w/sqm) thus more energy saving.
10 Cabinet type , Regular shape and special shape （such as curve, round), Easy for assembling and connection with the connector added
