Item | Flexible LED Screens |
Model Number | P5 |
Pixel Pitch | 5mm |
Pixel Density(dots/m²) | 40000 |
Pixel Configuration | RGB |
LED Type | SMD3528 |
Module size(mm) | 320*160 |
Module Resolution(dots) | 64*32 |
Min.Viewing Distance(m) | ≥5 |
Brightness(cd/m²) | ≥1000 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 300-750 |
Scan Mode | 1/16 |
Protection Level | IP21 |
Cabinet Size(mm) | 768*576 |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level: Color temperature is adjustable in terms of detailed requirements |
Working temperature | -20°C~80°C Life Span : 100,000hours |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Control Type | 3G/ WiFi /USB |
Product Features
1) LED flexible panel Soft PCB Board
2) Flexible LED screens Fixed with Magnetic Foot
3) Easy to assemble to different shape, inner arc, outer arc and right-angled LED sign
4) Fast connect data and power cable, front maintainable.
P5 arc/ round/ irregular Indoor LED Sign Module Parameters:
5) LED Type: SMD3528
6) Pixel Pitch: 5mm
7) Pixel Configuration: 1R1G1B
8) Module Size: 320*160mm
Important Knowledge of LED Display
1. How many panels can sending unit control?
The sending units is capable of controlling up to 1024 pixels (or 16 panels of 20mm) wide by 512 pixels (or 4 panels of 20mm) tall.
2. Maximal Power Consumption for LED displays
There are two types of driving methods for LED displays, which is the constant static driving method and the scan driving method. First let's explain how to calculate the maximal power consumption and average power consumption of a pitch 16mm LED display using constant static current driving.
3. What are Real, Actual and Virtual Pixel Pitches?
A virtual pixel pitch was a term associated with older LED screen technologies that shared LEDs to create virtual pixels. While this sounds impressive it didn’t really improve the picture greatly. A virtual pixel pitch is half the real or actual pixel pitch. So a virtual 10mm pixel pitch LED screen is actually a 20mm pixel pitch LED Screen.
4. What is the difference between an LED TV and LED Screens?
An LED TV (or LED backlit LCD) is a standard LCD monitor (like a flat screen LCD television or computer monitor) with LEDs positioned behind the LCD instead of a standard light source. It’s a little misleading so watch out!
5. Why use an LED Screen instead of an LCD Screen?
LED screens are a completely different technology to LCD screens, designed for a different purpose. LCD screens are designed primarily for indoor close viewing on a small scale. LED screens are designed for large scale, high impact projects that can be used outdoors in bright sunlight.
