Item | Indoor SMD Full Color LED Floor Tile Display |
Model Number | P7.62 |
Pixel Pitch | 7.62mm |
Pixel Density(dots/m²) | 17222 |
Pixel Configuration | 3 IN 1 |
LED Type | SMD3528 |
Module size(mm) | 244*244 |
Module Resolution(dots) | 32*32 |
Min.Viewing Distance(m) | ≥7.62 |
Brightness(cd/m²) | 1200-1500 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 140-300 |
Scan Mode | 1/16 |
Protection Level | IP21 |
Cabinet Size(mm) | 732*732 |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <120° |
Gray Scale | Recommended 14BIT |
Effective Communication Distance (without relay) | Unshielded twisted-pair net line transmission distance is 100 meters, max transmission distance is 130 meters |
Product Features
1) Installation area: They are ideal for applications in advertising, promotions, shopping malls, traffic control, concerts, sporting events.
2) Advertising forms: Texts, images, video, etc.
3) Brightness: 1200-1500 cd/㎡.
4) Large viewing angle: Horizontal 120 degree, vertical 120 degree.
5) Design of low power consumption, no need cooling fan, meet the demand of quiet work environment.
6) Message can be changed by your need in any time.
Important Knowledge of LED Display
1. What can I show on my LED Screen?
We can help you show anything you want on your screen. Plug in a laptop and show presentations, videos, and slideshows. We can take live video feeds and signals from your computers, vision mixers, or any output source including CV, VGA, HDMI, DVI, SDI, HD-SDI and more.
2. Does the panel has a fire certificate?
Yes. All of our panels meet standards for fire and power ratings.
3. How many panels can sending unit control?
The sending units is capable of controlling up to 1024 pixels (or 16 panels of 20mm) wide by 512 pixels (or 4 panels of 20mm) tall.
4. Can I rent your displays?
Yes. We have rental partners that can meet your needs for a rental solution. When you contact us make sure you choose rental and our staff will help facilitate this request.
5. Are your displays outdoor rated?
Yes. We do have solutions that can be utilized for permanent outdoor installation. Your sales representative can help you determine which products fit you best.
To receive a catalog,pricing information and a sample of a sign for your needs,just leave an Inquiry to get a Quick Quotation by those contact way.
