Item | Outdoor P5 LED Display Stadium |
Model Number | P5 |
Pixel Pitch | 5mm |
Pixel Density(dots/m²) | 40000 |
Pixel Configuration | RGB |
LED Type | SMD2727 |
Module size(mm) | 320*160 |
Module Resolution(dots) | 64*32 |
Min.Viewing Distance(m) | ≥5 |
Brightness(cd/m²) | ≥6000 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 240-480 |
Scan Mode | 1/8 |
Protection Level | IP65 |
Cabinet Size(mm) | Customized |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level: Color temperature is adjustable in terms of detailed requirements |
Working temperature | -40°C~80°C Life Span: 100,000hours |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Control Type | Asynchronization (3G/ WiFi /USB )/Synchronization |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <120° |
Product Features
1) We are not producer only, but also offer the whole solution for your specific LED display project, include: control system, software, installation drawing and tech support, etc.
2) Outdoor Fixed installation cabinet: Waterproof Protection,Standard: IP65/IP54.
3) Recommended size ratio 16:9. 4:3 Working Temperature: -30℃ ~ 40℃.
4) Mufti-function side holes,Hand for move.
5) Weight: 50KG/m2 Size: Customized.
6) Reference installation method: wall mounted curved type single/double pillar etc.
Important Knowledge of LED Display
1.What is DIP LED?
DIP LED are throught the DIP(Dual in-line package) technology,after soldering the led lamp's feet to stable it on the PCB .,so it names of DIP LED. It has high brightness and waterproof ,using for outdoor using.
2. What is SMD LED?
SMD led also named SMT(surface mounted technology),through the SMT technology encapsulating diode,solodering this lamp on the PCB board surface,should not plug the lamp feet to the PCB board,so it names SMD led moule, using for indoor.
3. Does your company offer OEM service?
Yes, We accept OEM.
4. Do you have any MOQ limit for led light order?
Low MOQ, 1pc for sample checking is available.
5. How to deal with the faulty?
Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new accessories with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
To receive a catalog,pricing information and a sample of a sign for your needs,just leave an Inquiry to get a Quick Quotation by those contact way.
