Product Description
Pixel pitch | P5 | ||
Module Parameters | Pixel pitch | 5 mm | |
Pixel Density | 40000 pixels/m2 | ||
LED Shape | SMD 3in1 | ||
LED Configuration | 1R1G1B | ||
Module Resolution | 64*32 pixel | ||
Module Size | 320*160 mm | ||
Drive Method | 1/16, 1/8 | ||
Cabinet Parameters | Cabinet Resolution | 128*128 | |
Cabinet Size | 640*640 mm | ||
Cabinet Weight | 28kg/m2 | ||
Display Parameters | Optical | Brightness | ≥1200 cd/m2 |
Viewing angle | H/V 160/160 | ||
Best Viewing Distance | 5-20 m | ||
Display Color | 16.7 million | ||
Grey Scale | 10bits/1024levels | ||
Power | Max power consumption | 1000 W/m2 | |
Ave power consumption | 500 W/m2 | ||
Working Voltage | 220V / 110V | ||
Control system | Frame Frequency | 60--85 HZ | |
Refresh Rate | 1200 HZ | ||
Data Transmission | CAT 5/ Optic Fiber | ||
Image Source | S-Video, PAL/ NTSC | ||
Controlling system | linsn, Nova | ||
Format | Video Compatibility DVI, VGA, composite | ||
Reliability | Working Temperature | -20~65 ℃ | |
Working Humidity | 10-95% RH | ||
Life Span | 100,000 Hours | ||
MTBF (Ave No Failure Time) | 5000 Hours | ||
Pixel failing Rate | 0.01% | ||
IP Rate | IP 21 | ||
Product Show
Module
Cabinet
Product Features
Light weight, Good Heat Dissipation, Low Power Consumption, Convenient Installation,
Easy Move;
Accurate position of the locating dowel makes the surface between cabinets flat;
Made through CNC, Assembly accuracy 0.1mm, Seamless Assembly;
No granular spots and mosiac on the screen, High-degree of color coordinates;
Clearer and vivider piture, Seamless, No chromatic;
Large viewing angle, Soft image, High resolution;
Multi-layer circuit PCB, Lower consumption, Fast Heat-emmiting, Longlife, High stability;
Aluminum Cabinet, Lighter and Slimmer, High accuracy;
Easy to assemble and detach the cabinets;
Working Noise: Less than 40DB, Have no influence on the viewing effect;
SMD2121 LED, Ultra-low decay, High stability, High color coordinates, Weather resistance;
High contrast ratio up to 5000:1;
SMD full color led chip.
FAQ
Q1:What's the min order quantity?
A: LED screen 1 sqm / LED module 100pcs
Q2: What is the payment method?
A:We support a variety of payment methods. Normally by T/T, 40% down payment,60% balance paid before shipping.
Q3: Is it ok to print my logo on led display product?
A: Yes, of course. If you need, please inform us before our production.
Q4: How long is the delivery time?
A: It's about 15-25days after confirmation of the order.
Q5: How do you ship the goods and how long does take to arrive?
A: We usually ship by sea or air. By sea is about 30-40days; by air is about 3-7days.
Q6: What's the control system do you use?
A: Our standard control system is Linsn or Novastar. Also support other controlling system, like Huidu,Sheenled,Colorlight etc.
Q7: Do you have any certification for LED display?
A: Yes, we have CE,ROHS,FCC certification.
Q8: How about the guarantee of led display?
A: We guarantee all our displays, modules, spare parts for two years.
