Item | P5 Indoor Full Color LED Display |
Model Number | P5 |
Pixel Pitch | 5mm |
Pixel Density(dots/m²) | 40000 |
Pixel Configuration | 3 IN 1 |
LED Type | SMD3528 |
Module size(mm) | 320*160 |
Module Resolution(dots) | 64*32 |
Min.Viewing Distance(m) | ≥5 |
Brightness(cd/m²) | ≥1200 |
Viewing Angle(degree) | ≤140° |
Average Power Consumption(w/m²) | 280-500 |
Scan Mode | 1/16 |
Protection Level | IP21 |
Cabinet Size(mm) | 640*640 |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Refresh Rate | LED screen refresh frame frequency recommended is 300-600HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <140° |
Gray Scale | Recommended 14BIT |
Effective Communication Distance(without relay) | Unshielded twisted-pair net line transmission distance is 100 meters,max transmission distance is 130 meters. |
Product Features
1) High intensity and can be adjusted, can meet the request of the customers according the application environment.
2) Best equality, have the excellent consistency of light.
3) To pictures and character, have clear, exquisite and real display effect.
4) Big viewing angle to 120-140 degree at horizontal line, 120-140 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion.
Important Knowledge of LED Display
1. What's the control system?
synchronization control system and asynchronous control system.
2. Whats your payment term? How long it takes to delivery?
We accept T/T and L/C, bank transfer,paypal etc. At least 40% deposit in advance, and the rest 60% before delivery.
3 Can it play HD video?
Yes, it can realize HD video function with controlling system.
4. What details need to be provided to get a quotation?
The buyer needs to provide pixel pitch,usage,dimension of screen and as more details as possible.
5. Can the LED table lamp be with eye-protection?
Yes.
To receive a catalog,pricing information and a sample of a sign for your needs,just leave an Inquiry to get a Quick Quotation by those contact way.
