Item | P4 Indoor Video Wall LED Panels Controller |
Model Number | P4 |
Pixel Pitch | 4mm |
Pixel Density(dots/m²) | 62500 |
Pixel Configuration | RGB |
LED Type | SMD3528 |
Module size(mm) | 256*128 |
Module Resolution(dots) | 64*32 |
Min.Viewing Distance(m) | ≥4 |
Brightness(cd/m²) | ≥1200 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 300-580 |
Scan Mode | 1/16 |
Protection Level | IP65 |
Cabinet Size(mm) | customized |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level, Color temperature is adjustable in terms of detailed requirements |
Working temperature | -20°C~80°C Life Span : 100,000hours |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Product Features
1) Large viewing angle: Horizontal 120 degree, vertical 120 degree.
2) LED video panels are ultra-bright in daylight sun.
3) Brightness: More than 1200cd.
4) Custom made fit designs, made to any shape to help you create the sleek and sophisticated design for any large open spaces.
5) Unconventional Unique LED custom design display screen tailor made with clean fittings to create seamless imagery with a pixel pitches from as small as 6.5mm-8mm giving crystal clear looks.
6) Unconventional Unique LED custom design display screen is perfect for making any large room more interesting, perfect for shopping centers, airports and other public large space, which is sure to turn heads.
Important Knowledge of LED Display
1. Do I need a technical person to assist installation and debugging the system to the screen?
Yes,normally it requests to send one or two technical persons to the installation site for assist,
as the perimeter/scoreboard will connect to different systems at the stadium,so, unless the buyer has professional engineer, we kindly suggest one or two engineers to be at site to help debugging the whole systems.
2. Do you give any discount?
I'll surely try my best to help you get those by the best price and good service at the same time.
3. I would like to ask you if it's possible to have my logo on the product?
We hope you know that our company USER perfectly support customized logo service. But, we also hope you know that it's an extraservice,so a little bit extra service fee is needed.
4. What details need to be provided to get a quotation?
The buyer needs to provide pixel pitch,usage,dimension of screen and as more details as possible.
5. What are your terms of delivery?
We accept EXW, FOB, CFR, CIF, DDU,or Express (fast delivery).
To receive a catalog,pricing information and a sample of a sign for your needs,just leave an Inquiry to get a Quick Quotation by those contact way.
