Description
Technical Parameters
If you're looking for the transparent led screen outdoor made in China, please rest assured to wholesale the screens with our professional manufacturers and suppliers in China. They are all made in our professional factory and are sold at low price.
transparent led screen outdoor
Feature:
1. Easy installation. If you need 5 person to install a normal screen, now with only one persona!
2. Transparent. Sunbeam entering the building while people appreciate the scenery outside.
3. Weighing 1/4 of a normal screen. Reduce the weight load of the building.
4. módulos.Para custom color that is suitable to color building.
Especificaciones
| Pixel Pitch(H) | 25mm | 25mm | 25mm | 25mm | 25mm |
| Pixel Pitch(V) | 25mm | 31.25mm | 35.71mm | 41.67mm | 50mm |
| Tamaño por unidad(mm) | 1200*250 | 1200*250 | 1500*250 | 1500*250 | 1500*250 |
| Cantidad de palo/unidad | 10pcs | 8pcs | 7pcs | 6pcs | 5pcs |
| Peso(kg/m2) | 15 | 14 | 9.6 | 8.6 | 8.5 |
| Resolución(dots/m2) | 1600 | 1280 | 1120 | 960 | 800 |
| Resolución de cada unidad(dots) | 48*10 | 48*8 | 48*7 | 48*6 | 48*5 |
| Brillo(Epistar, nit) | 7500 | 7000 | 6500 | 5800 | 5000 |
| Brillo(Nichia, nit) | 8000 | 7500 | 7000 | 6500 | 5500 |
| Transparencia | 60% | 68% | 72% | 76% | 80% |
| Temperatura de color(K) | 3200-9300 | ||||
| Ángulo de visión | H120°/V60° | ||||
| Permuta de palo | Horizontal/Vertical | ||||
| Uniformidad de brillo | ≥97% | ||||
| Uniformidad de color | ≤±0.003Cx, Cy | ||||
| Consumo de energía máximo | 450/m2 | 400/m2 | 345/m2 | 305/m2 | 255/m2 |
| Voltaje de entrada | AC220v/50Hz, AC110V/60Hz | ||||
| Método de conducción | Estático | ||||
| Tasa de refresco(Hz) | 1000 | ||||
| Escala de grises | 16384grado | ||||
| MTBF (horas) | 10,000 | ||||
| Temperatura de operación | -10℃ a +40℃ | ||||
Why do you use the transparent flexible mesh screen?
-to Replace the large cabinet and zorrero
-To See the sun even behind led display
-To Install with only two hands of a person
-To Save it in a corner of the house and do not need a warehouse
To clear idea and live without máscara!
