P8 High Brightness Trasparent Glass Led Display
DESCRIPTION
.In view of the TR series design purpose,facilitate fast installation and transportation, is the best choice for cultural and entertainment projects
2.The standard module size is simple and elegant
3.designed for easy installation, fast setup
4.Light: light screen multiplicity improve the installation efficiency
5.Thin: ultra-thin design, let the screen is perfect fusion with building
6.transparency:high transparency . Perfect lighting, visual like dreaming
7.saving: over then 50% of energy than traditional display, high efficiency and energy saving is your best choice
8.The PCB board is the most narrow in this line (3mm)
9. high transparency rate for front and back, have PC protection.
Item | P8 Glass Display Panels Signs with High Quality |
Model Number | P8 |
Pixel Pitch | 8*8mm |
Pixel Density(dots/m²) | 16667 |
Pixel Configuration | 1R1G1B |
LED Diode Type | SMD3528 |
Module size(mm) | 160*480 |
Module Resolution(dots) | 24*64 |
Cabinet size(mm) | 800*960 |
Cabinet resolution | 100x128dots |
Brightness(cd/m²) | ≥6500 |
Average Power Consumption(w/m²) | 240-800 |
Scan Mode | 1/2 |
Protection Level | IP20 |
Refresh Rate | 1000~1500 |
Transparent rate | >65% |
IC | MBI5124 |
Weight | 14kg/sqm |
Working temperature | -10℃~+40℃ |
Horizontal/Vertical viewing angle | <120° |
