Led Transparent Mesh Screen P10 Indoor Led Curtain Mesh Display

Item: P10 Transparent Glass LED Display Screen
Model Number: P10
Pixel Pitch: 10mm
Pixel Density(dots/m²): 1000
Pixel Configuration: 1R1G1B
LED Diode Type: SMD3528
Module size(mm): 320*320
Module Resolution(dots): 32*32
Cabinet size(mm): 320*320/960*320
Cabinet resolution: 32*32/96*32dots
Brightness(cd/m²): ≥6500
Average Power Consumption(w/m²): 240-800
Scan Mode: 1/2
Protection Level: IP20



Item | P10 Transparent Glass LED Display Screen |
Model Number | P10 |
Pixel Pitch | 10mm |
Pixel Density(dots/m²) | 1000 |
Pixel Configuration | 1R1G1B |
LED Diode Type | SMD3528 |
Module size(mm) | 320*320 |
Module Resolution(dots) | 32*32 |
Cabinet size(mm) | 320*320/960*320 |
Cabinet resolution | 32*32/96*32dots |
Brightness(cd/m²) | ≥6500 |
Average Power Consumption(w/m²) | 240-800 |
Scan Mode | 1/2 |
Protection Level | IP20 |
Refresh Rate | 1000~1500 |
Transparent rate | >70% |
IC | MBI5124 |
Weight | 14kg/sqm |
Working temperature | -10℃~+40℃ |
Horizontal/Vertical viewing angle | <120° |
