Led Stage Led Curtain Tv Display
Type Number | LightS-9.375 | Unit module composition | L1×H6module |
Pixel pitch(MM) | 9.375 | Unit module pixel | L32×H96dot |
LED Standard | SMD3528 | Max.power consumption | 135W |
Pixel composition | 3 IN 1 | Module material | PC |
Pixel density(dot/m2) | 11377 | Protection level | IP 65 |
Demensions(mm) | L300*W150 | Viewing angle | 110° |
Module Power | 25W | Working temperature | -20℃~+50℃ |
Module resolution(L×W) | 32*16 | Working humidity | 10%~90% RH |
Scan mode | 1/8 | Life span | ≥30,000 hours |
Grey | 65536 | Working voltage | AC 220 V / (110V) ±15% , 47~63 HZ |
Refresh rate(Hz) | ≥2000 | Signal transfer | Lan cable |
Brightness (CD/m2) | 2000 | Control system | LED FLASH Computer Control System |
Best viewing distance(M) | 9.5 | Computer platform | Windows XP,Windows 7 |
Unit module dimension | L300×H900mm | Video Sources available | DVD, VCD, VCR, TV, camera with PAL/NSTC |
Control case size | 535×200×150mm | Control pixel | L128×H192dot/L64×H384dot |
Control area dimension(mm) | L4×H2unit/L2×H4unit | Control case max.power | 1200W |
Control area dimension(mm) | W1200×H1800MM/W600×H3600MM | ||
Effetive control distance | ≤ 100 M (by LAN) , ≥ 100 M (by fiber optic with multi-module or single module) | ||
Packaging & Shipping
Our Services
1. We can provide customers a comprehensive solution delivery of series-related products.
2. We can provide customers high quality products which allow them to scream.
3. We can provide custom-made service.
4. We can provide customers one year free warranty, and support renewals extended.
5. We can provide customers the free installation guidance and technical support.
6. We are willing to provide any countries and regions in the world with products and technical support. At present, our product has covered more than 100 countries and regions.
Flexible video outdoo led stage led curtain tv display HD led mesh screen display for show
