Product Description
1. High transparency
More than 60% transparency, better transmittance. It may satisfy higher requirement of day-lighting, light transmission. Nearly imperceptible the LED display from a distance.
2. Slim & Light
22mm thickness, weight 20kg/sq.m, has little loading demand for the glass curtain wall and save freight and labor cost.
3. Quick & Easy installation
Standard size can be used to assemble larger displays. All power supplies and receiving cards are build into the modules, and power cables can easily be connected.
Model | P7.8 |
Pixel Pitch | 7.81mm |
LED Type | SMD3528 |
Pixel Density | 8192dots/m² |
Transparency | 48% |
Cabinet size | 1000mm X 500mm |
Cabinet Resolution | 128X64dot |
Cabinet Weight | 10kg/panel |
| Brightness | >900CD/m² |
Viewing Angle(H/V) | 140°/140° |
Viewing Distance | 8M |
Gray Scale | 14bits |
Max.Power Consumption | 500W/m² |
Ave.Power Consumption | 3000W/² |
Refresh Rate | 1200HZ |
Environment | INDOOR |
Support Input | Composite, S-Vido, Component, VGA, DCI, HDMI, HD_SDI |
Operation Power | AC 110V 240V 50/60Hz |
Operating Temperature | -20 ° C~45 ° C(work), -20 ° C~60 ° C(store) |
