SMD P10 Outdoor football sports stadium perimeter led display
一、Product information
P10 OUTDOOR LED SCREEN
Iron cabinet
Cabinet size:960*960mm
Product Features
1) Full color LED Display: The best choice for outdoor movie display system.
2) Input signal : HDTV, CATV, NTSC, PAL, S-video, VGA, VCD, DVD.
3) 1024 shades per color.
4) Slim thin: The depth of the LED Display is only 450px
5) Low power consumption, long life span, stable.
6) Super input system: Windows digital interface .
7) Automatically on/off function .
8) Fit for various network, standard connection socket, easy installation.
 |  |
Item | Outdoor mobile P10 SMD display |
Model Number | P10 |
Pixel Pitch | 10mm |
Pixel Density(dots/m²) | 10000 |
Pixel Configuration | 3IN1 |
LED Type | SMD3535 |
Module size(mm) | 320*160 |
Module Resolution(dots) | 32*16 |
Min.Viewing Distance(m) | ≥10 |
Brightness(cd/m²) | ≥6000 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 240-480 |
Scan Mode | 1/8 |
Protection Level | IP65 |
Cabinet Size(mm) | Customized |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level, Color temperature is adjustable in terms of detailed requirements |
Working temperature | -40°C~80°C Life Span: 100,000hours |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Control Type | Asynchronization (3G/ WiFi /USB )/Synchronization |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <120° |
