Description
Technical Parameters
If you're looking for the programmable flexible led display made in China, please rest assured to wholesale the screens with our professional manufacturers and suppliers in China. They are all made in our professional factory and are sold at low price.
programmable flexible led display
| Pixel Pitch | 4mm | Power Input | VH4 |
| Pixel Density | 62500dots/m2 | Signal Interface | HUB75D(IDC16) |
| Module Resolution | W64dots X H32dots | Brightness | ≥1000cd/m2 |
| Module Size | W256mm X H128mm | CIE | x=0.28;y=0.28 |
| PCB Board | 0.6mm soft board | Color Term. | 9500K |
| Drive Mode | 16bit Constant Current | Viewing angle | ≥140° |
| Scanning Mode | 16 | Best Viewing Distance | ≥4m |
| Operating Voltage | DC5V±10% | Working Clock | 15.6M Hz |
| Max Current | About 4A(TYP) | Gray Level | 12bits |
| Max Consumption | About 20W(TYP) | Load Range | W128dots H256dots |
| Brightness Chromaticity Correction | Support | Brightness Adjustable Range | 0 to 255 Adjustable |
| Refresh Rate | 1920Hz | Lifespan | 50,000 hours |
| Working Term. | -10 ℃ to 50 ℃ | Storage Term. | -30 ℃ to 80 ℃ |
| Working Hum. | 10%-80%RH(Without Condensation) | Storage Hum. | 10%-95%RH(Without Condensation) |
Flexible LED Display Panel Advantages:
1.High bright 3 in 1 LED SMD lamps with best plastic package suite are not easy to be damaged and ensures the best viewing angle.
2.Constant current chip driving IC MBI514 to reduces the power consumption and prompts the stability,Simple modular design for easy maintanence.
3Neat appearance,light weight,small size and safe 5V low voltage power supply system all make the module more attractive.
4.Due to its locating holes and 4 in bracket design,it can be used on indoor curved led display and circle led screen.
5.Besides,high definition effect comes with color uniformity and soft color is suitable for indoor close range viewing.
