p20 outdoor flexible led curtain soft led display
>>Parameters<<
Specification | Flexible curtain |
LED Lights | SMD 5050 3 in 1 |
Pixel Pitch | 20 mm |
Pixel Resolution | 2500 dots |
Pixel Composing | 1R1G1B |
Module Dimension(W*H) | 15mm*320mm*1280mm |
Single module Weight | 4.10kg |
Viewing Range | 20m to 66m |
Horizontal Viewing Angle | 135° |
Vertical Viewing Angle | 100°~120° |
Maximum Power Consumption | 210W/PCS ,513 |
Graphic card | DVI |
Control Method | synchronization |
LED Driver | constant current |
Scan mode | Static |
Frame Changing Frequency | ≥60Hz |
Refresh Rate | ≥1000Hz |
Brightness | ≥5000cd |
Ingress Protection (Front/Rear) | IP66 |
Operation Temperature | (-40°C~50°C) |
Operation Humidity | 10%~95% |
Input Voltage | AC220V/110V±15% 47-64Hz |
Gray Scale | 4096 |
Brightness Adjustment | 256 level |
System Operating Platform | WINXP,WIN2000,WIN98 etc |
Support Mode | DVI,VGA,S-Video,RGBHV,COMPOSITION etc |
Control System | DVI graphic card+control card(gigabyte)+optical fibre transmission(option) |
NTBF | ≥50000 hours |
Life Time | 100000 hours |
>>Details<<
>>Feature and Advantage<<
1. Brightness: >5000 cd/m2. the pixel can be adjusted point by point to reach the white balance.
2. Special design, the screen can be curved to any shape.
3. Without steel frame, the screen is very light, it is good for building body. only using a hanging bar, it can be installed easily and fast
4. High refresh rate: 4000 Hz. It is suitable for high-end video camera
5. With strip moudel.
