Product Features
1) P4 LED flexible screen module with small-unit and flexible design,makes possibility of more complicated shapes for the video show.
2) P4 flexible LED video screen magnet connection,easy to assemble & disassemble,it is frontal service maintenance.
3) No cabinet metal frame,drastically deducting the screen weight.we can design any shape of structure as you need.
4) You Assembling screen with LED flexible screen soft led modules directly,saving time and effort,easy operation.
5) Strict quality control and long-term application experience verified the stability and excellent performance by using Nastionstar LED, and MBI5124 Driving IC for high refresh rate and performance.
6) Widely applied in shaped stage background/exhibition/shopping mall etc.
Item | Flexible LED Display Panels |
Model Number | P4 |
Pixel Pitch | 4mm |
Pixel Density(dots/m²) | 62500 |
Pixel Configuration | RGB |
LED Type | SMD3528 |
Module size(mm) | 256*128 |
Module Resolution(dots) | 64*32 |
Min.Viewing Distance(m) | ≥4 |
Brightness(cd/m²) | ≥800 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 300-750 |
Scan Mode | 1/16 |
Protection Level | IP21 |
Cabinet Size(mm) | 512*512 |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level: Color temperature is adjustable in terms of detailed requirements |
Working temperature | -20°C~80°C Life Span: 100,000hours |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Control System | Linsn/Nova |
Control Type | 3G/ WiFi /USB |
P4 Indoor Flexible LED Display Video Panels Screen For Sale
