Full Color Led Soft Curved Panel Rgb Led Module P6.66 Flexible Led Screen

If you're looking for the full color led soft curved panel rgb led module p6.66 flexible led screen made in China, please rest assured to wholesale the screens with our professional manufacturers and suppliers in China. They are all made in our professional factory and are sold at low price.



Full color led soft curved panel rgb led module P6.66 flexible led screen



Product Description







ltem		PH6.66(Full Color)PH6.66RGB
Unit Cabinet	Pixel pitch	6.66mm
	LED type	3-in-1 SMD3535 /3528SMD
	Pixel Density	22,545/sqm
	Module Size	320*160mm
	Pixel Composition	1R1G1B
	Cabinet Size	960*960mm
	Cabinet Resolution	144*144
	The Optimum View Distance	6-66m
Main Specification	Viewing Angle	Horizontal 160°Vertical 140°
	Maximum Power consumotion	1,000W/sqm
	Driving Components	Constant Current driving
	Driving Scan	1/16 DrivingScan
	Frame Frequency	≥60Hz
	Refresh rate	≥1080Hz
	Luminance of white balance	6,000cd/sqm
	Working environment temperature	Storage -40℃~+85℃;Working -20℃~+50℃
	Working  voltage	220V±10%or110V±10%
	Grey Scale/Color	Grey Scale≥16384 Grade  Each Color≥16384 grade
	Brigtness adjustment	Synchronization system SDI/HDSDI,HDMI,DVI,VGA,VCBS,DP,YpbPr,etc.
	Computer System	WIN XP,WINDOWS7
	Input single	SDI/HDSDI, HDMI, DVI, VGA, VCBS, DP, YpbPr, etc.
	Control system	DVI graphics+send card +card transmission+receiving card/gigabit nice+receiving card
	Life time	≥100,000 Hours
	Defects Rate	<0.0002
	Data interconnection	(CAT5 Cable ) ( L≤140m );( multi-mode fiber ) ( L≤500m );( single mode fiber ) ( L≤20km )



LED Parameters

Item	Luminous Intensity	View Angle(H/V)	Wavelength	Test Condition
Red LED	700-910mcd	160°/140°	620-630nm	25℃,20mA
Green LED	1500-1894mcd	160°/140°	520-535nm	25℃,20mA
Blue LED	325-403mcd	160°/140°	465-475nm	25℃,20mA

Indoor features:



1. SMD3-IN-1 technology are used for indoor LED display
2. wide view angle:140 inhorizonal and 140 in vertical
3. special design and advanced SMT technology improves the heat dissipation
4. with high fresh rate controller, guarantee that no scan line when taking photos
5. regular shape and special shape(such as curve,round) can be designed
6. easy for assembleing and connection with the connector added
7. high color uniformity and clear image can bring you a vivid audio visual effect
8. both front access and rear access areavailable





 Advantage :



1.Wide viewing angle: Viview led display show clear pictures or image without mosaics even when audiences see it from a small viewing angle;
2.Rich colors: With three basic colors (red, green and blue), 256-level gradation of each color, and form 16777216 kinds of colors;
3.Adjustable brightness: Viview LED screen brightness can be adjusted automatic and manual according to environment light;
4. Good color blending: Display clear, exquisite, nature color video even at close distance;
5. Wide range of display content: Viview led wall can easily to display txt documents, doc documents, pictures (BMP/JPG/GIF/PCX…..) and video (MPG/MPEG/MPV/MPA/AVE/VCD/SWF/RM/RA/RMJ/ASF)
Viview led display usage range: Governmental plazas, Large-scale entertainment plazas, business and commercial centers, playground, station, airport and so on.
