Waterproof P10 Full Color Led Display Screen
LED full color display
It consists of a red LED chip, a green LED chip and a blue LED chip. The unit module contains a driver
chip and an input buffer chip, which are connected to the LED display control. The system can display
video, image and text information; driven by the signal can be formed color conversion; this unit can be
horizontal and vertical direction of any splicing, which spelled into different sizes of the display.
Product Parameter
Item | P10 outdoor Led |
Model Number | P10 |
Pixel Pitch | 10mm |
Pixel Density(dots/m²) | 10000 |
Pixel Configuration | 3 IN 1 |
LED Type | SMD3535 |
Module size(mm) | 320*160 |
Module Resolution(dots) | 32*16 |
Min.Viewing Distance(m) | ≥10 |
Brightness(cd/m²) | >5500 |
Viewing Angle(degree) | ≤140° |
Average Power Consumption(w/m²) | 550-900 |
Scan Mode | 1/4 |
Protection Level | IP65 |
Cabinet Size(mm) | 960*960 |
Product Description
LED display module features:
1, the use of ultra-high brightness LED and high-quality plastic pieces
2, high-contrast hue can achieve a good display
3, light weight, easy to install, remove
4, can be single-point, single lamp maintenance, low cost
5, using constant current way to drive LED, light uniformity, low power consumption
6, the pixel pitch is 10mm, a total of 32*16 pixels, each pixel consists of 1R1G1B
the above methods can be used outside
If you have a more reasonable installation, but also in full accordance with your request!
In order to meet the indoor and outdoor environment, LED display module edge irrigation
water glue (ie, silicone + curing agent), after spraying three anti-paint
Application:
