Description
Technical Parameters
Feature:
High weight load-bearing
With rubber seal,suitable for outdoor application besides indoor.
With die casting materials, each cabinet is only 13kg, greatly save transportation cost.
Adjustable base support to make the screen surface extremely flat
Taking any panel from front side no need to remove any other tiles
Fan-less design make the screen very quiet. It’s very important used in TV studio, concerts, etc.
500×500mm (W×H), easy to calculate and assemble big screen within limited time.
Many pixel pitch displays optional such as 3mm, 4mm, 5mm , 6mm.
Product details
Product parameter
| Pixel pitch(mm) | 3 | 4 | 5 | 6 |
| Pixel density(dot/㎡) | 111111 | 62500 | 40000 | 27777 |
| Module resolution(dots) | 64*64 | 64*32 | ||
| LED type | SMD2121 | SMD3528 | ||
| Brightness(cd/㎡) | 1200 | |||
| Scan mode | 1/32s | 1/16s | ||
| Cabinet size(mm) | 500*500 | |||
| Average power(w) | 350-600 | 400-780 | ||
| Input voltage | AC220V/50HZ or AC110V/60HZ | |||
| Protection level | IP43 | |||
| Lifespan | 100000hours | |||
| Refresh rate | 1200HZ | |||
