[ Characteristic of LED Video Dance Floor]
These are LED floor panels that have many indiviual LEDs distributed thoughout 1024 Resolution Video Dance Floor Panelthe space of the panel; very much like the pixels on a television.
They are available in different resolutions from low to high.
With video floors its easy to create virtually anything you can watch on a TV monitor on the entire floor.
Audiences are treated to entertaining moving graphics while they dance or just watch.
Great for special occassions, holidays, corporate events with logo displays, weddings and dance clubs. Video and graphics can be played back on these floors with a computer or laptop
| Pixel pitch | P10 | ||
| Module Parameters | Pixel pitch | 10 mm | |
| Pixel Density | 10000 pixels/m2 | ||
| LED Shape | SMD | ||
| LED Configuration | 1R1G1B | ||
| Cabinet Parameters | Cabinet Resoltuion | 64*64 | |
| Cabinet Size | 640*640 mm | ||
| Display Parameters | Optical | Brightness | ≥1200 cd/m2 |
| Viewing angle | H/V 120/120 | ||
| Best Viewing Distance | 10-30 m | ||
| Display Color | 16.7 million | ||
| Grey Scale | 10bits/1024levels | ||
| Power | Max power consumption | 1000 W/m2 | |
| Ave power consumption | 500 W/m2 | ||
| Working Voltage | 220V / 110V | ||
| Control system | Frame Frequency | 60--85HZ | |
| Refresh Rate | 1500HZ | ||
| Data Transmission | CAT 5/ Optic Fiber | ||
| Image Source | S-Video, PAL/ NTSC | ||
| Controlling system | linsn, Nova, Mooncell, ZD, Xixun, Lumen, Dbstar | ||
| Format | Video Compatibility DVI, VGA, composite | ||
| Reliability | Working Temperature | -20~65 ℃ | |
| Working Humidity | 10-95% RH | ||
| Life Span | 100,000 Hours | ||
| MTBF (Ave No Faliure Time) | 5000 Hours | ||
| Pixel failing Rate | 0.01% | ||
| IP Rate | IP 63 | ||
Advantages
Ultra-slim design,metal housing, non-skid treatment toughened glass cover.
Outdoor or indoor using, protection level can reach IP63.
Controlled by LED Flash Computer Control System.
Can play various lighting effects, words, graphics, flashes, videos, etc.
