P5 Indoor LED Displays Description:
1).For indoor display,super bright,support any format of video.
2).Easy and simple installation interface and user friendly software to ensure the easy
operation the indoor LED display system.
3).Our indoor LED displays are widely used in commercial advertising, indoor led video wall,indoor background led display,entertainment industry, financial industry, communications, power sector, traffic, stadium, plaza, school, airport etc., for advertising and displaying messages.
P5 Indoor LED Displays specifications:
| Pixel Information | Pixel Pitch | 5mm |
| Pixel Configuration | SMD 3 in1 | |
| LED Module | Module Size(mm) | 320(Width) × 160 (Height) |
| Module Resolution | 64(Width) × 64 (Height) | |
| Cabinet | Cabinet Size(mm) | 640(Width) ×640(Height) |
| Cabinet Resolution | 128 (Width) × 128(Height) | |
| Total QYT Module Per Cabinet | 5(Width) ×5(Height) | |
| Cabinet Weight | 40kg/㎡ | |
| Power | Input Voltage | 780Watt/㎡ |
| Avg. Power Consumption | 400 Watt/㎡ | |
| Brightness | 1500cd/㎡ | |
| Best Viewing Angle | Horizontal:140° | |
| Best Viewing | 5m | |
| Ambient Conditions | Temperature Range | Working:-20deg. to +60deg |
| Operating Humidity | 10%90%RH | |
| Ingression Protection Grade | IP21 | |
| Processing | Scanning Mode | 1/16S |
| Refresh Frequency | 1920HZ, Adjustable(depends on control system) | |
| Signal Input | DVI, Composite Video for Live Video | |
| Supported Networking | Through LAN/WAN, RS 232/RS485 |
Cabinet
Application field :
Advertising LED displays, Stadium perimeter LED screen, Mobile led display for mobile media, shopping mall LED billboard for logo showing, bank & stock exchange LED messager signs for rates showing, train & bus station, airport, telecommunication LED video wall system for information showing and instruction, Stage performances and so on.
