Product Parameter:
Item | P6 Indoor Full Color LED Display |
Model Number | P6 |
Pixel Pitch | 6mm |
Pixel Density(dots/m²) | 27777 |
Pixel Configuration | 3 IN 1 |
LED Type | SMD3528 |
Module size(mm) | 192*192 |
Module Resolution(dots) | 32*32 |
Min.Viewing Distance(m) | ≥6 |
Brightness(cd/m²) | ≥1200 |
Viewing Angle(degree) | ≤140° |
Scan Mode | 1/16 |
Protection Level | IP21 |
Cabinet Size(mm) | 768*576 |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Refresh Rate | ≤1200HZ |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <140° |
Gray Scale | Recommended 14 BIT |
Effective Communication Distance(without relay) | Unshielded twisted-pair net line transmission distance is 100 meters,max transmission distance is 130 meters. |
Module:
Cabinet:
Application：
Features:
1) high brightness, adjustable, could be used in different environment.
2) Unique waterproof processing,moisture-proof, anti-static and dust free.
3) Bigger viewing angel by 3 IN 1 SMD, better color mixture and gorgeous image quality.
