product features:
（1）colorful：(Red, green, blue) display unit board composition, red, green and blue 256 levels of gray composition of 16,777,216 kinds of colors, so that P4 indoor high-definition display display color rich, high saturation , High resolution, high frequency display of dynamic images;
(2) the effect is good: the use of non-linear correction technology, the image clearer, more layered;
(3) reliability: the use of distributed scanning technology and modular design technology, reliability, stability, higher;
(4) the new mask design, so that the light emitted by the LED almost 0 reflection to ensure that the screen display effect;
(5) high flatness: box flatness coefficient <0.5mm, power factor up to 88% or more;
(6) durability: the use of high temperature spray technology, greatly improve the anti-rust function; luminous module warranty for ten years, the mask is not reflective, UV resistance, five years do not fade;
Item | Outdoor Full Color LED Display |
Model Number | P4 |
Pixel Pitch | 4mm |
Pixel Density(dots/m²) | 62500 |
Pixel Configuration | 3 IN 1 |
LED Type | SMD2121 |
Module size(mm) | 256m*128m |
Module Resolution(dots) | 64*32 |
Brightness(cd/m²) | ≥1200-1500 |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 300-580 |
Scan Mode | 1/16 scan |
Protection Level | IP21 |
Cabinet Size(mm) | 512*512 |
