If you're looking for the hd p2.5 indoor led video display/led advertising display screen/p2.5 led display panel made in China, please rest assured to wholesale the screens with our professional manufacturers and suppliers in China. They are all made in our professional factory and are sold at low price.
HD P2.5 Indoor Led Video Display/led Advertising Display screen/p2.5 Led Display Panel
Features:
1. Small pitch, high definition;
2. Perfect & vivid images;
3. Most competitive price;
4. Good after-sale.
Module Parameter:
| Pixel pitch | 2.5mm |
| Pixel Density | 160,000 dots/m² |
| Pixel configuration1 | 1R1G1B |
| LED type | 3-in-1 black SMD 2121 |
| Module size | 160*160mm |
| Module weight | 209g |
| Module resolution | 64*64dots |
| Module quantity | 39.06 pcs/m² |
| Min. Viewing Distance | ≥2.5m |
| Brightness | ≥800 cd/m² |
| Viewing Angle | H≤120° V≤120° |
| Driving Mode | 1/32 scan constant current driving |
| Interface | HUB75E |
| Input voltage | 4.8-5.5VDC |
| Max. Power Consumption | 800 w/m² |
| Avg. Power Consumption | 400 w/m² |
| Max. Current | 3.3-3.6A |
| Frame rate | 60 frames/s |
| Refresh Rate | ≥600Hz |
| Defective Dots Rate | <0.0001 (LED display line standard: ≤ 0.0003) |
| Decay Rate | ≤5%/year |
Brightness Conformity | >95% |
| MTBF | ≥10000 hours |
| Lifespan | ≥50000 hours |
| Protective function | Over-heat/Over-load /Power-down /Power-leakage/Lightning -protection etc. |
| Operating Temperature | -20℃~+50℃ |
| Operating Humidity | 10-85% no condensation |
| Storage Temperature | -30℃~+60℃ |
| Storage Humidity | 10-95% no condensation |
Control System Parameter
| Color temperature | Adjustable by software |
| Brightness control | 256 levels, automatic adjustment. |
| Control way | Computer, real-time, off-line, wireless, network etc. |
| Communication Distance | Cat5 UTP 100 meters, max. 130 meters; or optical fiber. |
