Item | Single Red |
Model Number | P10 |
Pixel Pitch | 10mm |
Pixel Density (dots/m²) | 10000 |
Pixel Configuration | 1R |
LED Type | DIP |
Module size(mm) | 320*160 |
Module Resolution(dots) | 32*16 |
Min. Viewing Distance(m) | ≥10 |
Brightness | ≥2000cd/㎡ |
Viewing Angle(degree) | ≤120° |
Average Power Consumption(w/m²) | 500-850 |
Scan Mode | 1/4 |
Full color LED display mainly consists of several major components:
1, the external large frame structure: the role is to carry parts, so that parts complete a full color LED display auxiliary material, is also indispensable.
2, the display unit module: LED display screen that is a piece of the screen.
3, scan control circuit board: the role of data buffer, resulting in a variety of scanning signals and control signals.
4, the power switch: the AC power into a DC switching power supply.
5, the transmission cable: the main console to transfer data to the full color LED display above the conductor.
6, the main console: control and send a variety of signals.
7, the video processor: deal with the transmission of video data, can handle live video.
8, computer and peripherals: such as: computer, U disk, radiator and so on.
