Single Color Outdoor Led Display/Screen/Signboard
---Specifications---
1. Screen Dimension: customized
2. Overview: led moving message sign
3. Purpose: advertising, release information and beautify
4. Test time: >72 hours
5. Function: Display text and picture
6. Transport way: Express, air transportation or ocean shipping
7. Cabinet material: Waterproof iron
8. Warranty: 1 year
9. Experience: 6 years
---Parameters---
Item | Parameter |
Name | led moving message sign |
Brightness | ≥2000 cd/sqm (outdoor) |
Viewing Angle | 120° |
Driver Mode | 1/4 constant current |
Working Temp | -20°C~+60°C |
Working Hum | 10%~90% RH |
Microchip | Red 9 from OPTOTECH, green and blue 10*12 from Silan |
Diameter of leds | 5mm |
Pixel pitch | 10mm |
Voltage | AC100~240V |
Power Consumption | 20W--40W |
Control mode | RS232, RS485 serial port, remote, U disk and wireless |
Material of Frame | Waterproof iron |
Composing Parts | LED display, software, data line and adapter |
Multi language | English/Chinese/Greek and more |
Format | Bmp, jpeg, gif picture format, even gif animation display |
Brightness adjustment | Manual and automatic by time period |
On and off mode | Manual/automatic powered |
Auxiliary function 1 | Self-contained clock and spare battery not paused once powered off |
Auxiliary function 2 | Can extend temperature and hygrometer display (need extra charge) |
Computer operation request | WIN XP or VISTA, WIN 7 |
---Why choose led moving message sign? ---
LED moving message sign bring you these advantage:
1. Release different information and advertisement.
2. Display picture/video/text and attract attention.
3. Good looking and colorful effect can beautify your project.
4. Message can be change by your need in any time.
5. High brightness low power consumption.
6. We can design different type by your need.
7. Controlled by computer or U disk.
8. It can display time
---Case Show---
P10 Outdoor Single Color Red LED Module RGB LED Screen With WiFi
