P8 Outdoor Led Display Price
Product Description
Affordable, Rugged And Durable, Multi-Material Selectivity, Easy Assembly And Disassembly, Protect The Environment And So on.
Our System Uses LED Light Source Light, The Intensity Of Its Life And Light Are Very High.
The Product Can Be Widely Used In Indoor And Outdoor, Street, Next To Highways, Airports, Commercial Hall And So on.
Product Parameters
Item | P8 Outdoor Led Display Price |
Model Number | P8 |
Pixel Pitch | 8mm |
Pixel Density(dots/m²) | 15625 |
Pixel Configuration | 3 IN 1 |
LED Type | SMD3535 |
Module size(mm) | 256*128 |
Module Resolution(dots) | 32*16 |
Min.Viewing Distance(m) | ≥8 |
Brightness(cd/m²) | >6300 |
Viewing Angle(degree) | ≤140° |
Average Power Consumption(w/m²) | 550-900 |
Scan Mode | 1/8 |
Protection Level | IP65 |
Cabinet Size(mm) | 1024*1024 |
Technical Specifications
With Excellent Waterproof Performance, Safe And Reliable Power System
All Components Of The Product Can Be Processed According To Customer Requirements.
The Metal Structure Can Be Recycled Again Without Any Impact On The Environment.
Product Life Of Up To 1000000 Hours.
We Can Provide Additional Installation, Technical Guidance And Training Services.
LED display
LED full color display
It consists of a red LED chip, a green LED chip and a blue LED chip. The unit module contains a driver chip and an input buffer chip, which are connected to the LED display control. The system can display video, image and text information; this unit can be horizontal and vertical direction of any splicing, which spelled into different sizes of the display.
LED display module features:
1, the use of ultra-high brightness LED and high-quality plastic pieces
2, high-contrast hue can achieve a good display
3, light weight, easy to install, remove
4, can be single-point, single lamp maintenance, low cost
5, using constant current way to drive LED, light uniformity, low power consumption
6, the pixel pitch is 8mm, a total of 32 * 16 pixels, each pixel consists of 1R1G1B
