Product Description
P6 Led Advertising Display Screen Board Product Detail
1. Outdoor HD LED Display Leader
Outdoor HD LED Display leader, mature product, functions two years ahead of competitors, worldwide fantastic projects. Standard Modules help clients upgrade to better resolution. Increase the chance to have the second sales and enhance the relationships with clients.
2. Protection Rate IP65 and Module Style Design
Protection rate IP65, installation without frame. Module Style Design, fast installation and easy maintenance with low cost.
3. No Distortion, Power and Control System Back-up Technology
Deep black surface, firm & flat, anti-UV mask, make sure the flatness and no distortion. Power and control system back-up technology solution available.
P6 Led Advertising Display Screen Board Application Places
Ideal for outdoor advertisement media, government& enterprise project, culture & tourism, sports, propaganda image, commercial real estate.
item | Specification | |
Panel | panel dimension | 192mm*192mm |
panel pixel pitch | 6mm | |
panel pixel density | 27777dots/M² | |
panel canfiguration | 1R1G1B | |
LED specification | SMD2727 | |
panel pixel resolution | 32*32dots | |
Average power | 10W | |
panel weight | 0.455kg | |
panel power supply | 5V40A | |
cabinet | Cabinet size | 960mm*960mm |
Best viewing angel | H:>170°,V:>120° | |
Best viewing distance | 6~100M | |
working tempreture | -20~+65 | |
Technical parameter | Screen power supply | AC 220V~250V |
Max power | 700W/M² | |
Average power | 350W~500W/M² | |
Driving device | 16016 constant current drive | |
Drive type | 1/8 scanning | |
Refresh frequence | 240-1000HZ/S | |
display color | 4096*4096*4096 | |
Brightness | >7000cd/M² | |
Communication distance | 100m | |
