P4 Outdoor Street Lighting Pole Led Display
Street Light Pole LED Display With Remote mass control: 3G/4G control without distance limit, massive LED display control synchronously;
Free WiFi: People nearby LED display search its WiFi,identify and log in, then surf on the ineternet freely;
Interactive: Our R&D is dedicated to realize interactive functions between LED display advertising and customers;
Item | Outdoor Full Color LED Display |
Model Number | P4 |
Pixel Pitch | 4mm |
Pixel Density(dots/m²) | 62500 |
Pixel Configuration | 3 IN 1 |
LED Type | SMD2121 |
Module size(mm) | 256*128 |
Module Resolution(dots) | 64*32 |
Min.Viewing Distance(m) | ≥4 |
Brightness(cd/m²) | ≥7000 |
Viewing Angle(degree) | ≤140° |
Average Power Consumption(w/m²) | 500-850 |
Scan Mode | 1/8 |
Protection Level | IP65 |
Cabinet Size(mm) | Customized |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements. |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <120° |
Gray Scale | 14BIT Recommended |
Effective Communication Distance(without relay) | Unshielded twisted-pair net line transmission distance is 100 meters, max transmission distance is 130 meters. |
