Product Features
1. Accurate position of the locating dowel makes the surface between cabinets flat;
2. Made through CNC, Assembly accuracy 0.1mm, Seamless Assembly;
3. No granular spots and mosiac on the screen, High-degree of color coordinates;
4. Clearer and vivider piture, Seamless, No chromatic;
5. Large viewing angle, Soft image, High resolution;
6. Multi-layer circuit PCB, Lower consumption, Fast Heat-emmiting,Longlife,High stability;
7. Easy to assemble and detach the cabinets;
8. Working Noise: Less than 40DB, Have no influence on the viewing effect;
9. smd led, Ultra-low decay, Weather resistance;
10. High contrast ratio up to 5000:1.
P10 LED Module
Product Parameters
Item | Outdoor Full Color LED Display |
Model Number | P10 |
Pixel Pitch | 10mm |
Pixel Density(dots/m²) | 10000 |
Pixel Configuration | RGB |
LED Type | SMD3535 |
Module size(mm) | 320*160 |
Module Resolution(dots) | 32*16 |
Min.Viewing Distance(m) | ≥10 |
Brightness(cd/m²) | ≥5500 |
Viewing Angle(degree) | ≤140° |
Average Power Consumption(w/m²) | 550-900 |
Scan Mode | 1/4 |
Protection Level | IP65 |
Cabinet Size(mm) | 960*960 |
Color Temperature | The brightness of R.G.B.is adjustable according to software 100level;Color temperature is adjustable in terms of detailed requirements |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Refresh Rate | LED screen refresh frame frequency recommended is no less than 1200HZ(recommended) |
Color | 64g color(on the condition of 4096 gray scale) |
Horizontal/Vertical viewing angle | <120° |
Gray Scale | 14BIT Recommended |
Effective Communication Distance(without relay) | Unshielded twisted-pair net line transmission distance is 100 meters,max transmission distance is 130 meters. |
Package
