How to ensure safety:
LED transparent screen in the installation and put into use, in addition to daily maintenance and maintenance, but also to do a good job in the installation of practical work, the following is a safe operation guide for your use:
Fire safety LED transparent screen installation and use of safe operation instructions
Avoid electric shocks:
1. before any installation or maintenance is done, the power must be completely turned off.
2. The connection between the product and AC must be disconnected before using the product or repairing or installing any parts of the product.
3. ensure that the product is adequately grounded.
Product Parameter
| Pixel Pitch(mm) | 3.91 |
| Pixel Density(dots/㎡) | 32768 |
| Module Resolution(dots) | 64*64 |
| Module Size(mm) | 250*250 |
| LED type | SMD2020 |
| Brightness(cd/㎡) | 1500 |
| Cabinet Size(mm) | 500*1000 |
| Power Consumption(w) | 500-750 |
| Protection Level | IP43 |
Product Description
Very see-through, without any change of architechtural appearance and transparency of glass wall,create the open view in large space indoors and make advertising emerge into architechture and life.
Customization: tailored according to the size of glass wall.
Modularization: design a variety of box structures and size.
Easy installation: the weight is 12kg ~ 15kg. can be directly attached on the glass curtain wall free with extra steel frame.
High contrast: 1500:1 contrast, vivide image.
New advertising: new and unique display effect, the picture is suspended above the glass curtain wall.
Product Packaging
