LightS P40 Flexible Led Screen Curtain Wall
Product Features
1) With creative graphics, video, text and animation you can create truly dynamic content, combined with our full color led screens, it will grab people’s attention and keep it !
2) Outdoor LED curtain display with high resolution images, animation and text is certainly a powerful medium for advertising.
3) The cabinets are constructed to IP65 waterproof rating and are thoroughly tested to ensure the very best standard are complied with.
4) High brightness levels in excess of 6000 ensure exceptional picture quality in direct sunlight.
5) The LED curtain screen modules are available with either front or rear service access, which can be specified to meet the requirements of your particular installation.
6) Using black SMD3535 LEDs means that the quality is further enhanced,the SMD LEDs used to construct the screens are from the same batch to further ensure color uniformity.
P40 Outdoor Flexible LED Video Curtain Screen with Competitive Price | |
Model Number | P40 LED Curtain Display Screen |
Pixels | 40mm |
LED Type | SMD3535 |
Pixel Density | 1089 |
Module size(mm) | 3000mm*1000mm |
Module Resolution | 75*25 dots |
Refresh Frequency | ≥1200HZ |
Usage/Tube Chip | Outdoor/3 IN 1 |
Scan Mode | Static |
Average Power Consumption | 100-280(w/sq.m) |
Min.Viewing Distance(m) | ≥40m |
Brightness | ≥6000 nits |
Horizontal/Vertical viewing angle | <140° |
Working temperature | -20°C~80°C |
Protection Level | IP65 |
Iron Cabinet Size(mm) | customized |
Input Voltage | AC220 V/50HZ or AC 110V/60HZ |
Color | 64g color(on the condition of 4096 gray scale) |
Gray Scale | Recommended 14BIT |
Color Temperature | The brightness of R.G.B. is adjustable according to software 100level; Color temperature is adjustable in terms of detailed requirements |
Life Span | 100,000hours |
MTBF | 10,000hours |
Environment Temperature | Storage: -40°C~+85°C |
Blind Spot Rate | ＜0.0001(led display industry standard is less than 0.0003) |
Control Mode | Video frequency synchronization |
FAQ:
Q1: How to help client choose suitable led display?
A1: (1)application palce (2)viewing distance
(3)display brightness (4)budget and cost control, obviously its our first concern for we both
Q2: What about your technical support of led display?
A2: Proffessional engineers are on standby, can offer guidance, on site technical support as required for led display installation & maintanence
Q3: What's the control system of led display?
A3: For led display of synchronization control: Nova, Linsn or Mooncell control system.
For led display of asynchronous control: Onbon or Xixun control system.
Q4: What's the warranty of your LED displays?
A4: We provide 2 years warranty and conditioned lifetime technical support for our LED display products.
Q5: What's your payment of led display?
A5: Our payment method is T/T 40% as deposit, balance before delivery.
Our Service:
After-sale service:
1. Lifetime free maintenance and upgrade.
2. Complaint respond in 24 hours; maintenance guidance and problem
solution given in 48 hours.
3. Customer satisfactional tracking report
4. Free technician training.
5. Full set of documents free of charge, which including installation
guidance, software operation tutorial, easy maintenance manual and
control system software video and so on.
6. Special service for big project, such as stadium, exhibitions, squares
and so on.
Product transportation time in detail:
ODM Service: the sizes of our ODM curtains include xxxxxxx, triangle shape and so on.. Customers can purchase sample at any time and we usually ship sample by DHL within one week.
OEM Service: If you have any specific requirement, please feel free to inform the size, shape color ofthe LED and your favorite hung method, and etc. The cooperation details can be negotiated by both sides
