P10 SMD Outdoor LED Display TV Video Wall Waterproof And High Definition

P10 SMD Outdoor LED Display TV Video Wall Waterproof And High Definition

1 High definition (10,000dots/sqm) with an outstanding image and video quality for indoor usage 2 Wide view angle:140 in horizonal and 90 in vertical.for indoor full color 3 High refresh rate (greater than 800Hz-4000Hz)with software adjustable, suitable for filming. 4 High gray scale (16 bits)...

Product Details

1  High definition (10,000dots/sqm) with an outstanding image and video quality for        indoor usage



2  Wide view angle:140 in horizonal and 90 in vertical.for indoor full color



3  High refresh rate (greater than 800Hz-4000Hz)with software adjustable, suitable for    filming.



4  High gray  scale (16 bits) with perfect visual performance.



5  High Contras ratio (3000:1) with black mask and black coating technique.



6  High color uniformity and clear image can bring you a vivid audio visual effect.



7  Special design and advanced SMT technology for indoor led screen

   improves the heat dissipation for indoor led signboard



8  High reliability and long lifespan (MTBF ≥ 5000 hours).



9  Low power consumption(200w/sqm) thus more energy saving.



10 Cabinet type , Regular shape and special shape such as curve, round),

   Easy for assembling and connection with the connector added



11 Items: BESD-IFP4,BESD-IFP5,BESD-IFP6.BESD-IFP7.62,BESD-IFP8,BESD-IFP10



Model:BESD-IFP10



Pixel pith

10mm

Module size(mm)

320 x 160mm

Pixel configuration

1R1G1B ( 3in1 )

Module density(dots)

32 x 16dots

View Angle

140°/120°

Pixel density

10,000dots/

LED encapsulation

SMD3528 3in1

Refresh rates

≥600Hz or ≥2000Hz

Driving Method

1/8 scan,constant current

Max power consumption

600w/

Cabinet size

Normal 640x 640mm or
Designed by requirements

Cabinet material

Aluminum alloy or Iron, Steel

Cabinet thickness

< 8 cm or Designed by requirements

Cabinet weight

< 10kg/cabinet or Designed by require

Brightness

>1600nits

Type Power consumption

300w/

Working voltage

AC110 / 220V +- 15%

Working temp

-20℃to +60℃

Best viewing distance

>6 m -300meter

Working humidity

 35%~85%

LED parameters

R:620-625nm
IV:250-300mcd

MTBF

 > 5,000hours

G:520-523nm
IV:800-1000mcd

Gray Level

 > 8192 grade

B:467-470nm
IV:200-230mcd

Lifespan

 > 100,000hours



Image processing

Video de-noising , rapid motion compensation, edge sharpening, edge smoothing,color coordinate conversation& control , grey scale transformation etc

Brightness uniformity

Ratio of min pixel brightness /max pixel<0.9(When each color reaches its highest brightness)

Effective control distance

Cat-5<100M,Multi-mode fiber:<500M;Single-mode fiber<20Km

Color Temperature/contrast

Brightness and contrast of red, green and blue can be adjusted by software,100 scales are available, color temperature is adjustable

Input signal

RF,S-VIDEO,RGB,RGBTV,YUT,YC,COMPISITION

Control system

Sending card+ Receiving card+ Hub card+ DVI Card+ PCTV Non-liner card+ Multi-functional card(Optional)+Video processor(Optional)+ Fiber Transmitter(Optional)

1.jpgAll weather proof, stable and reliable

IP65/IP55 rating for both waterproof and sunscreen, it is fully suitable for outdoor all-weather use. Good performance of dust-proof, moisture proof and corrosion ensures long-term use in harsh outdoor environments.





2.jpgHigh-quality materials, safety certification

Adopts high-quality flame retardant materials and dual-use sheet metal for anti-UV and safer operational environment. In the meanwhile, L10D has passed rigorous testing and authentication, such as salt spray test, VDE certification etc. Durable plugs allows insertion and removal over 2, 000 times.



3.jpgExcellent display quality, perfect picture

Up to 6000cd / m 簡 brightness, low-grayscale processing, even in direct sunlight, the picture is still clear.

4.jpg EMC certification, safety and health

Products are designed in strict accordance with the requirements of the design to minimize radiation to reduce the impact on the environment and the harm to human body.



5.png Environmental protection, energy efficiency

Adopt efficient PFC power supply, synchronous rectification to achieve a variety of functions, over-temperature protection, overload protection, over-current protection, short-circuit protection features that make conversion efficiency up to 90%, to ensure the stability of the LED display operation.

If you're looking for the p10 smd outdoor led display tv video wall waterproof and high definition made in China, please rest assured to wholesale the screens with our professional manufacturers and suppliers in China. They are all made in our professional factory and are sold at low price.
