Outdoor P10 SMD Modules And IP65 Cabinet

Outdoor P10 SMD Modules And IP65 Cabinet

Product features Extraordinary colour presentation and ultra high contrast ratio Compact CNC workmanship, ultra-thin aluminium profile structure Water-proof module design, 100% front and rear maintenance allowed 40% energy-saving by natural cooling.

Product Details

Outdoor P10 SMD modules and IP65 cabinet

Product features

Extraordinary colour presentation and ultra high contrast ratio

Compact CNC workmanship, ultra-thin aluminium profile structure

Water-proof module design, 100% front and rear maintenance allowed

40% energy-saving by natural cooling.


P10 outdoor SMD full color led module .JPG



Item: Outdoor Full   Color LED Display
  Model Number: P8
  Pixel Pitch: 8mm
  Pixel Density(dots/m²): 15625
  Pixel Configuration: RGB
  LED Type: SMD3535
  Module size(mm): 256*128
  Module Resolution(dots): 32*16
  Min.Viewing Distance(m): ≥8
  Brightness(cd/m²): ≥7000
  Viewing Angle(degree): ≤140°
  Average Power Consumption(w/m²): 500-850
  Scan Mode: 1/4
  Protection Level: IP65

FAQ



Important Knowledge of LED Display

1. What is LED?

LED stands for Light Emitting Diode, a kind of semiconductor which is used to give and receive the electronic signal into infrared rays or light, using the characteristics of compound semiconductor. This is used for household appliances, remote controller, electric bulletin board, various kinds of automation appliances.

2. What are Pixel Pitch, Pixel Density, LED QTY and Pixel Configuration?

Pixel Pitch is the distance between neighboring pixels.

Pixel Density is the quantity of pixels per square meter.

LED QTY is the quantity of LED lamps per square.

Pixel Configuration is the description of the consistence of a pixel. For instance, we use 1 red lamp, 1 green lamp, and 1 blue lamp to compose a pixel, the pixel configuration is 1R1G1B.

3. What are LED Type, Module Size and Module Resolution?

LED Type is the description of LED lamp. For instance, the brand, the shape in physical, the size of the lamp etc.

Module Size is the measurement of a module.

Module Resolution is the number of pixels per module.

4. What is Drive Method, Driving IC and Power Supply?

Drive Method:  We always use static, 1/4 scan, 1/8 scan, 1/16 scan, the latter one contributes to less brightness than the former. We always use the static outdoor, and use the different kinds of scan indoor.

Driving IC is the generic term for several kinds of IC, which are used to control the LED lamps, and as a bridge between the control system and lamps.

Power Supply: a kind of device that used as a transfer from 220V AC into 5V DC. It always seems like a box in the cabinet.

5. What is Viewing Angle?

Viewing angle is the maximum angle at which a display can be viewed with acceptable visual performance. It includes horizontal viewing angle and vertical viewing angle.
